Product specification
BrandPolycab
Product CategoryAluminium Power Cable
Size of Conductor16 sq mm
Core3 Core
Conductor MaterialAluminium
ColourBlack
Overall Diameter (Strip/Wire)19.7 mm
Current Rating73 Amp
Thickness of PVC Insulation0.7 mm
Min.thickness of pvc inner sheath0.3 mm
Nominal Dimensions of Armoui (Strip / Wire)1.6 mm
Min. Thickness Of PVC Outer Sheath (Strip / Wire)1.4 mm
Max DC Resistance ohm1.91 Ohm
Max. AC Resistance ohm2.44 Ohm
Approx. Reactance at 50Hz Ohms/Km0.08
Capacitance mFd/Krr0.36
Manufacturer DetailsPolycab India Limited, Unit 4, Plot No.105, Halol Vadodara Road, Village Nurpura, Taluka Halol, Panchmahal, Gujarat - 389350, India
