Features

  • Safe : ABB MCB's have finger touch proof terminals conforming to IP20 degree of protection. Hence ABB MCB's prevent from electrical shock when it contacts human body.
  • Tropicalization : These MCB's are tropicalized, hence they are safe to use in high humid environment.

Technical Data

  • Standards : Double Pole
  • Tripping Characteristics : C Curve
  • Rated Current : upto 63A
  • Rated Voltage : 400/415 V AC
  • Max Operating Voltage : 400 V AC
  • Min Operating Voltage : 12 V AC
  • Rated Frequency : 50/60 Hz
  • Rated Short – Circuit Capacity : 10kA
  • Over Voltage Category : lll
  • Pollution Degree : 2

So, anytime if there is a spike in line voltage or a sudden increase in line current, then this MCB will trip, causing the circuit/power to break, thereby eliminating any associated damage to the connected appliance/load.

Product specification
BrandABB
Product CategoryDouble Pole MCB
SeriesN/A
Current Rating63 Amp
Triping CharacteristicsC-Curve
Short Circuit Withstand Capacity10kA
ColourWhite
Voltage230 / 400 V AC
Rated Operating Voltage Ue440V
Insulation Voltage500 V
Nominal Frequency50/60 Hz
Mounting TypeOn symmetric rail EN/IEC 60715 or DIN 35 rail.
Package Contents1 DP MCB
CertificationIEC 60947-2
MaterialHalogen-Free Plastic Materials
Warranty2 Years (against manufacturing defects)
Manufacturer DetailsABB India Limited, #126, Hanchipura Village, Kasaba Hobli, Nelamangala Taluk, Bangalore, Karnataka - 562123, India
