This 25A Three Pole C-Curve 10kA Miniature Circuit Breaker from the house of Hager is an innovatively designed MCB that protects an electric circuit from any sort of damage caused by overloading or short circuits. So, anytime if there is a spike in line voltage or a sudden increase in line current, then this MCB will trip, causing the circuit/power to break, thereby eliminating any associated damage to the connected appliance/load.

Product specification
BrandHager
Product CategoryThree Pole MCB
Current Rating25 Amp
Triping CharacteristicsC-Curve
Short Circuit Withstand Capacity10kA
ColourWhite
Voltage230 / 400 V AC
Rated Operating Voltage Ue440V
Insulation Voltage500 V
Nominal Frequency50/60 Hz
Mounting TypeOn symmetric rail EN/IEC 60715 or DIN 35 rail.
Package Contents1 TP MCB
CertificationIEC 60947-2
MaterialHalogen-Free Plastic Materials
Warranty2 Years (against manufacturing defects)
Manufacturer DetailsHager Electro Private Limited, B-217, Tower B, Dlf Towers, Jasola, Delhi - 110025, India
