This 6A SP C-Curve 10kA MCB is a single pole highly durable MCB with finger touch proof terminals conforming to IP20 degree of protection. It is used in Single Phase Supply to break the phase only. It is ideal for the protection against overload and short circuit for Lighting & other Domestic Loads. So, anytime if there is a spike in line voltage or a sudden increase in line current, then this MCB will trip, causing the circuit/power to break, thereby eliminating any associated damage to the connected appliance/load.

Product specification
Product CategorySingle Pole MCB
Current Rating6 Amp
Triping CharacteristicsC-Curve
Short Circuit Withstand Capacity10kA
Voltage240 - 415 V AC
Rated Operating Voltage Ue440V
Insulation Voltage660 V
Nominal Frequency50 Hz
Mounting TypeOn symmetric rail EN/IEC 60715 or DIN 35 rail.
Package Contents1 SP MCB
CertificationIS/IEC 60898-1
MaterialHalogen-Free Plastic Materials
Warranty2 Years (against manufacturing defects)
Manufacturer DetailsHavells India Ltd., QRG Towers, 2D, Sector - 126, Expressway, Noida, Uttar Pradesh - 201304, India
