Company Cat No: 4086 12

The DX3 MCB series are suitable both for commercial and residential installation.


  • Integrated label holder for circuit identification.
  • Bi-connect terminals for cable and busbar.
  • Safety shutter.
  • ISI Marking and also Internationally certified.
  • Insulated sliding shutter.
  • Two position DIN rail clamp
  • Large cable terminals of 35mm2 capacity for better terminal.

Technical Data:

  • Standards : SPN (Single Pole + Neutral)
  • Tripping Characteristics : C Curve
  • Rated Current : 10A
  • Rated Voltage : 240/415 V
  • Rated Short - Circuit Capacity : 10kA

This DX3 408612 10A SPN MCB  is a single pole highly durable MCB with finger touch proof terminals conforming to IP20 degree of protection. It is used in Single Phase Supply to break the phase only. It is ideal for the protection against overload and short circuit for Lighting & other Domestic Loads.

Product specification
Product CategoryDouble Pole MCB
SeriesLegrand DX3
Current Rating10A
Triping CharacteristicsC-Curve
Rated Short-Circuit Capacity10kA
Voltage230 / 400V AC
Rated Operating Voltage Ue440V
Insulation Voltage500V
Nominal Frequency50/60 Hz
Mounting TypeOn symmetric rail EN/IEC 60715 or DIN 35 rail.
Package Contents1 DP MCB
CertificationIEC 60947-2
MaterialHalogens-free plastic materials
Warranty2 Years (on manufacturing defect)
